Inmarsat Beam Covert Anti-Piracy Antenna (CVTINM)

MSRP $1,145 USD

The BEAM Inmarsat Covert antenna has been specifically designed for the maritime market to help against Pirates boarding a vessel and destroying all communication antenna’s to restrict any crew from communication with the outside world.

Read more product features

Inmarsat Beam Covert Anti-Piracy Antenna Features

Discreet Antenna

It is the only antenna designed not to look like an antenna, thus disguising it with the normal non-communication equipment you would expect to see on a vessel. The Covert antenna can be used with any of the BEAM Inmarsat docking units or Oceana fixed maritime units.

Key Benefits and Features

• IP66 rated enclosure
• Looks like a normal maritime light
• Polycarbonate housing
• Enclosure fits ISD710 Inmarsat Antenna
• Easy to install
• Same for install as ISD710
• Antenna pre fitted inside
• Supports both Satellite / GPS cables
• Custom designed by Beam

Inmarsat Beam Covert Anti-Piracy Antenna Specifications

General

RF Output Impedance Axial Ratio 50 Ohms
Intended Operating Environment Maritime
Equipment Type Mobile or Fixed Base Station
Operational Band ≤ 4dB, 0° ≤ 0 ≤ 85°
Extended Band ≤ 6dB, 0° ≤ 0 ≤ 85°
Antenna Description Type Maritime

Frequency

Inmarsat Transmit (operational) 1626.5 to 1660.5 MHz
Inmarsat Transmit (extended) 1668.0 to 1675.0 MHz
Inmarsat Receive (operational) 1525.0 to 1559.0 MHz
1575.42 ± 10.25 MHz (GPS L1)
Inmarsat Receive (extended) 1518.0 to 1525.0 MHz

Power

Antenna Power DC Power supplied by IsatDock MARINE No additional power box required

Environmental

Temperature Degrees °C Degrees °F
Temperature Range -40°C to + 70°C -40°F to 158°C

Physical

Dimensions mm inches
Box 260 W x 210 D x 160 H 10.24 W x 8.27 D x 6.69 H
Weight kg lbs
Box 1.38 3.04

Connectors

Inmarsat (GSPS) SMA
GPS SMA

Accessories

Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD932_1
Beam ISD932 Inmarsat 6m (20 feet) antenna cable kit provides a flexible installation option for ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD933_1
Beam ISD933 Inmarsat 13m (43 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD934_1
Beam ISD934 Inmarsat 18m (59 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD935_1
Beam ISD935 Inmarsat 31 metre (102 feet) antenna cable provides the ability to run long ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD938_1
Beam ISD938 Inmarsat 40metre (131 feet) antenna cable provides the ability to run long distance ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD942_1
Beam ISD942 Inmarsat 50m (164.0 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD943_1
Beam ISD943 Inmarsat 60m (196.85 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD944_1
Beam ISD944 Inmarsat 70m (229.7 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD945_1
Beam ISD945 Inmarsat 80m (262.47 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD946_1
Beam ISD946 Inmarsat 90m (295.3 feet) antenna cable provides a flexible installation option for most ...
View product
Inmarsat_IsatDock_Oceana_SMA_TNC _Cable Kit_ISD947_1
Beam ISD947 Inmarsat 100m (328.1 feet) antenna cable provides a flexible installation option for most ...
View product

Inmarsat Beam Covert Anti-Piracy Antenna Features

Discreet Antenna

It is the only antenna designed not to look like an antenna, thus disguising it with the normal non-communication equipment you would expect to see on a vessel. The Covert antenna can be used with any of the BEAM Inmarsat docking units or Oceana fixed maritime units.

Key Benefits and Features

• IP66 rated enclosure
• Looks like a normal maritime light
• Polycarbonate housing
• Enclosure fits ISD710 Inmarsat Antenna
• Easy to install
• Same for install as ISD710
• Antenna pre fitted inside
• Supports both Satellite / GPS cables
• Custom designed by Beam

Inmarsat Beam Covert Anti-Piracy Antenna Specifications

General

RF Output Impedance Axial Ratio 50 Ohms
Intended Operating Environment Maritime
Equipment Type Mobile or Fixed Base Station
Operational Band ≤ 4dB, 0° ≤ 0 ≤ 85°
Extended Band ≤ 6dB, 0° ≤ 0 ≤ 85°
Antenna Description Type Maritime

Frequency

Inmarsat Transmit (operational) 1626.5 to 1660.5 MHz
Inmarsat Transmit (extended) 1668.0 to 1675.0 MHz
Inmarsat Receive (operational) 1525.0 to 1559.0 MHz
1575.42 ± 10.25 MHz (GPS L1)
Inmarsat Receive (extended) 1518.0 to 1525.0 MHz

Power

Antenna Power DC Power supplied by IsatDock MARINE No additional power box required

Environmental

Temperature Degrees °C Degrees °F
Temperature Range -40°C to + 70°C -40°F to 158°C

Physical

Dimensions mm inches
Box 260 W x 210 D x 160 H 10.24 W x 8.27 D x 6.69 H
Weight kg lbs
Box 1.38 3.04

Connectors

Inmarsat (GSPS) SMA
GPS SMA
