Iridium Beam Aero Patch Antenna TSO Approved (RST719)
The Beam RST719 TSO Aero Approved Iridium patch antenna, is designed for aero applications with C-144 TSO Approval.
Features
The antenna is supplied complete with bulkhead mount that enables it to be securely mounted without the connectors being exposed to the environment and fitted with a TNC connector. The RST719 is designed to be low profile and aero dynamic.
Key Features
• Iridium approved
• Designed for harsh environments
• Small and lightweight
• Aluminium alloy casting
• TSO approved C - 144
• Manufactured in the USA
• 12 month repair or replacement warranty
• Designed for harsh environments
• Small and lightweight
• Aluminium alloy casting
• TSO approved C - 144
• Manufactured in the USA
• 12 month repair or replacement warranty
Similar items you may be interested in
Specifications
General
| Polarization | Right Hand Circular |
| Axial Ratio | 3db Max |
| Impedance | 50 OHMS |
| VSWR | < 2.0 : 1 |
| Altitude | 21,336m/70,000ft |
| TSO Approved | C -144 |
Frequency
| Iridium | 1595 ± 30MHz (-1.5dB band width) |
Environmental
| Temperature | Degrees °C | Degrees °F |
| Operating Temp | -55°C to +85°C | -67°C to 185°C |
Physical
| Colour | White | |
| Finish | Polyurethane | |
| Material | A380 Aluminum Alloy – casting. Ultem 2200 Radome | |
| Dimensions | mm | inches |
| Antenna | 20.83H x 88.9 Dia | 0.82H x 3.50 Dia |
| Weight | kg | lbs |
| Antenna | 0.22 | 0.5 |
Connector
| Iridium | TNC Female |
Brochures
Brochure RST719 Iridium Aeronautical Patch Antenna
For more information please download our RST719 Iridium Aeronautical Patch Antenna Brochure.
Download brochure
